Display Mode: 4 digits LED
Lamp: Halogen-Tungsten Lamp
Interface: RS232 Serial & parallel
Measurement: 370×320×190mm
Weight: 9.5Kg
Features
â–²Curny-terner configuration diffraction grating monochromator, A spherical light source optics & Precise grid, whole aluminum metal alloy die-castings.
â–²Pre-aligned lamp and spectral engery correction system.
â–²Simple & clear keyboard operation is convenient to realize auto 0% & 100% adjustment and error-free T/A transformation.
â–²Factor setting & direct concentration readout functions.
â–²Serial & parallel interface, LSG22 data processing software package & serial printer are spare parts.
â–²Spacious sample compartment, 4 position cell rack, adaptable for 1-5 cm optical path rectangular cells.
Specificatios
Wavelength Range:         340-1000nm
Wavelength Accuracy:        2 nm
Wavelength Reproducibility:   1 nm
Band width:           6 nm
Photometric Accuracy:      0.5%(T)(SRM930D)
Photometric Reproducibility:   0.3%(T)
Stray Light:           ≤0.5%(T)
Scale: TRANS:          0-199.9%
ABS:             -0.3-2.999
FACT:             1-9999
CONC:            0-9999
Standard Package
1) LSG22 spectrophotometer      1 Set
2) 1 cm glass cuvette          2 Cases
3) 1cm 4 position cuvette rack       1 PC.
4) Power cable             1 PC.
5) Operation manual            1 PC.
6) Certificate of quality checking      1 PC.
7) Fuse (2A)               1 PC.
Optional Spare Parts and Accessories
1) Fuse (2A/3A)
2) Pre-aligned lamp
3) Glass cuvette 1 cm, 2 cm, 3 cm,5cm
4) 5 cm cuvette rack (suitable for 1-5cm cuvette)
5) Spectrophotometer data processing software package
6) RS-232C serial cable
7) Praseodymium-Neodymium optical filter
8)LSG22 data processing software Features
MODE: T/A/ STANDARD CURVE/ QUANTITATION
DATA PRINT/OUTPUT/SAVE
