Display Mode: 128╳64 LCD

Lamp: Halogen-Tungsten Lamp

Interface: RS232 Serial

Measurement: 372×360×200mm

Weight: 10Kg

Features

â–²Curny-terner configuration diffraction grating monochromator, non-spherical light source optical path & Precise grid, whole aluminum metal alloy die-castings.

â–²128×64 dots LCD.

â–²Simple & clear keyboard operation is convenient to realize auto 0% & 100% adjustment and error-free T/A transformation.

â–²Factor setting & direct concentration readout functions.

â–²As much as 24 items of working curve equations can be preserved for long time.

â–²First order curve fitting can be performed.

â–²With 2K E2PROM.

â–²Spacious sample compartment, 4 position cuvette rack, suitable for 1-5 cm optical path rectangular cells.

Specificatios

Wavelength Range:　　　　　　　340-1000nm

Wavelength Accuracy:　　　　　　±2nm

Wavelength Reproducibility:　　　≤0.5nm

Band width:　　　　　　　　　　 4nm

Photometric Accuracy:　　　　　　0.5%(τ) (NBS SRM930D)

Photometric Reproducibility:　　　0.3%(τ)

Stray Light: 　　　　　　　　　　 ≤0.5%() (360nm, NaNO2)

Scale:　TRANS:0-199.9%

ABS: -0.3-2.999

FACT: 1-9999

CONC: 0-999

Standard Package

1. LSG527S spectrophotometer 　　　 1 set

2. Power cable　　　　　　　　　 1 pc

3. Operation Manual　　　　　　 1 pc

4. Certificate of quality checking　 1 pc

5. Fuses（2A）　　　　　　　　 2 pcs

6. 1cm glass cuvettes　　　　　    2 cases

7. 1cm 4 position cuvette rack　　  1 pc

8. Packing list 　　　　　　　　　 1 pc

Optional accessories and spare parts

1. Fuse（2A/3A）

2. Pre-aligned lamp

3. Glass cuvette 1cm、2cm、3cm、5cm

4. 5cm cuvette rack（suitable for 1-5cm cuvette）

5. RS-232C Serial cable

6. Praseodymium-Neodymium optical filter

7. Holmium oxide optical filte

8. printer                        1 pc
