Parameters：

Two parameters：SPO2, Pulse Rate.

Waveforms:

No waveform.

Features：

1、Tiny, light, "all-in-one" integrated clip design, easy for carrying;

2、LED screen with SpO2, PR and Pulse strength measurements;

3、Immediately, real-time spot-check;

4、Single button interface, easy for operation,

5、Common AAA alkaline or rechargeable batteries to support 3 continuous working hours;

6、Low battery power indicator;

7、Automatic power-off.

Dimension: 67x38x36mm

Net Weight: 60g

Gross Weight: 0.15kg

Package Size: 130x75x45mm

Color: White

Technical specification

[Specifications]

SpO2

Measurement range: 35~100%

Accuracy: (70~100%), 0~69% unspecified

Resolution: 1%

Pulse Rate

Measurement range: 30-250 bpm

Resolution: 1bpm

Display Mode

SpO2 display: 1-digit of 2-segment and 2-digit of 7-segment red LED

PR display: 3-digit of 7-segment red LED

Pulse strength display: A 6-segment red LED bar-graph

Low battery power indicator: A red LED

Environment Requirements

Temperature:

Working: 0~40oC

Transport and storage: 20~60 oC

Humidity:

Working: 15~95% (non-condensing)

Transport and storage: 10~95% (non-condensing)?

Altitude:

Working: 86 KPa ~ 106 Kpa

Transport and storage: 50KPa ~ 106 Kpa

Power Requirements

Battery type: Two common 1.5V AAA alkaline or rechargeable batteries
