This product provides the excellent image quantity with high resolution and definition the selectable multiple transducers, powerful measuring and analysising software package extend its application to broader fields.
Full Digital Technology
Full digital engine with non tortured echo ensuring high definition images.
Excellent image Quality
Originating from the full digital technology
Advanced image processing.
Technical specification:
Scanning mode: Convex/Linear
Display modes: B,B+B,B+M,M,4B
Scanning depth: 60-130mm (6.5MHz Rectal Linear)
Cine-loop: 511frames (Max)
Image permanent storage: 32 frames
Image conversion: up/down, left/right, black/white
Local zoom: 2times both in real –time and frozen
Measurement: distance, circumference, area, volume, EF rate, heart rate
OB measurements: Equine-CA (GSD)
 Bovine-GA (BL, SL, HL)
Swine—GA (HL)
Sheep—GA (USD)
Cat------GA, EDD (HD, BD)
Dog-----GA, EDD (GSD, CRL, HD, BD)
Probe connector: 2
Port: PAL-D Video out, USB2.0
Monitor: 10 inch SVGA
Comment: date&time, name, sex, age, doctor, hospital,
Annotation (whole screen comment input)
Standard Configuration: 6.5MHZ Rectal Linear
Optional configuration: 7.5MHZ LINEAR
5.0MHZ Micro-Convex
3.5MHZ Convex cart
Video printer
