Digital beam-forming and dynamic aperture technology

Excellent image quality

Dual socket, scanning angle 8-16 level adjustable

Gamma correction, 8-segment GTC

Automatic report generation (normal/OB)

Abundant software packages for full clinic applications such as abdominal, obstetric, gynecology, cardiology, urology, small parts, etc.

Real-time image display, image freezing, amplifying, black- white reversing, up and down conversing, and upgrading in depth

Standard PAL-D and VGA video output

General gain control, near field and far field (T.G.C) control, brightness and contrast adjustment

Foldaway keyboard and trackball ensure fast, convenient and flexible operation

809 frames of Cine-loop and 32 frames of permanent storage

USB 2.0 interface ensures real-time image transfer to PC


Included as standard accessories

 2.5/3.5/5.0Mhz convex probe

Fuse (2 pcs)

 Gel (1 pc)

USB software CD & cable(1 pc)

Optional at additional cost

 5.0/6.5/7.5Mhz trans-vaginal probe

6.5/7.5/8.5Mhz linear probe

6.5/7.5/8.5Mhz endo-rectal probe

4.5/5.0/5.5Mhz micro-convex probe
